113-2824 Mounting Base, High Pressure Cylinder Warning
Cat® Mounting Bracket (Base) with ISO High-Pressure Injection Hazard Warning Plate, for Track Adjusting Cylinder, Dimensions: 90 X 111 X 119 mm
Wholesale only · Full payment before shipment · Send your machine nameplate to confirm fitment
Description
113-2824 is a steel mounting bracket with a warning plate that identifies the high-pressure spray hazard of the hydraulic track adjuster cylinder.
Features
- Steel mounting bracket (plate) with hazard warning plate
- Bracket Color: Black
- Used with M10 or 3/8 in fasteners
- Slotted holes for easy assembly
- Warning Plate Material: Aluminum
- Warning Plate Color: Safety yellow background with black characters and symbols
- Warning Plate Symbol: Fluid – High-Pressure Manual Injection; Read Operator's Manual [ISO 0790]
- Warning Plate Message: Warning: High-pressure injection hazard. Can penetrate the body and may cause serious injury or death. Read the Operator's Manual
Applications
Located on the track adjuster cylinder. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Type | Warning Plate |
|---|---|
| Overall Length | 90 mm (3.5 in) |
| Overall Width | 111 mm (4.4 in) |
| Overall Height | 119 mm (4.7 in) |
| Material Thickness | 3 mm (0.1 in) |
Compatible Equipment
- Generator Sets: 3512B
- Excavators: 330D L, 329D L, 336E L, 325D L, 330D2, 336D2 L, 320D FM, 325C, 336D2 GC, 325D, 336D L, 329E L, 336E, 336F, 320C, 330C, 336F L, 325B L, 336D2 XE, 336F LN, 330D, 330D2 L, 328D LCR, 330 L, 330B, 330C L, 325C L, 336E H, 336F L XE, 336E LH, 336E LN, 325B, 335F LCR, 329E, 320D, 336D2, 329D, 336D, 329D2, 329D2 L
Additional information
| Machine Model | 320C, 320D, 320D FM, 325B, 325B L, 325C, 325C L, 325D, 325D L, 328D LCR, 329D, 329D L, 329D2, 329D2 L, 329E, 329E L, 330 L, 330B, 330C, 330C L, 330D, 330D L, 330D2, 330D2 L, 335F LCR, 336D, 336D L, 336D2, 336D2 GC, 336D2 L, 336D2 XE, 336E, 336E H, 336E L, 336E LH, 336E LN, 336F, 336F L, 336F L XE, 336F LN, 3512B |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
