Description
An information decal mounted on the instrument panel, used to identify the functions and settings of switches and indicator lights.
Features
- Right-hand film
- Color: Black background with white characters and symbols
- Symbols: On/Start [IEC 5007]; Off/Stop [IEC 5008]; Rear Window – Washer and Wiper [ISO 0096]; Parking Lights [ISO 0240]; High Beam [ISO 0082]; Work Lights [ISO 1204]
- Film Size: 543 x 68 mm (21.36 x 2.68 in)
- Polycarbonate film
- Pressure-sensitive adhesive backing
Applications
Located on the instrument panel. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Material | Polycarbonate Plastic |
|---|---|
| Type | Information Film |
| Film Color | Black |
| Lettering Color | White |
| Length | 543 mm (21.36 in) |
| Width | 68 mm (2.68 in) |
Compatible Equipment
- Track Loaders: 826H, 824G, 826G, 834H
- Wheel Loaders: 950G, 972G, 962G, 980G, 988H, 988G
