111-1815 Cylinder Block Bushing
Cat® bushing for replaceable sleeves or inserts in the cylinder block, installed in the bore of the engine cylinder block
Description
The Cat cylinder liner forms a sliding surface for the piston rings that retains lubricant and is manufactured to strict tolerances designed to ensure a perfect fit with existing cylinders on Cat machines.
Features
- End flange
- OEM direct replacement part
Applications
Used inside the cylinder block to act as the inner wall into which the piston slides. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Overall Height | 109.22 mm (4.3 in) |
|---|---|
| Overall Length | 228.6 mm (9 in) |
| Overall Width | 109.22 mm (4.3 in) |
| Width | 121.92 mm |
| Height | 121.92 mm (4.8 in) |
| Length | 254 mm (10 in) |
Compatible Equipment
- Cold Planers: TH360B
- Wheel Excavators: IT14G, M315
- Compactors: CS-563E
- Excavators: 312C, 312C L
- Wheel Loaders: 924GZ, 928G
Additional information
| Machine Model | |
|---|---|
| Equipment Type | Excavators, Wheel Excavators, Wheel Loaders, Compactors, Cold Planers |
| Part Source | Genuine OEM |
