Description
Cat® fastener parts are designed for specific applications based on size, strength, clamp load and past performance, information other manufacturers do not have. They are carefully selected to last until machine rebuild or end of life. Non-Cat hardware and fasteners may appear to fit your machine, but no one else knows your equipment the way we do.
These bolts can be installed when there is not enough clearance to use hex head bolts.
Features
- Cat fasteners are manufactured to precise specifications for durability, reliability and high efficiency
- Strength and Quality – Fasteners meet or exceed ISO, ASTM, ASME and SAE requirements.
- Cat bolts, nuts and washers are specifically designed to work together as a system to maximize clamping force.
- Coating meets the special requirements of different applications (RoHS compliant).
Applications
Cat bolts form a high-performance system with mating hardened washers and nuts to produce consistent, high clamping force. You can trust Cat fasteners to help you build, maintain or rebuild in most machine and shop applications worldwide.
Specifications
| Thread Direction | RH |
|---|---|
| Material | Nylon, 6, 6/12, 6/6 Plastic |
| Handle Length | 2.1 mm (0.083 in) |
| Locking Feature | Nylon Patch |
| Bolt Type | Socket Head |
| Bolt Length | 10 mm (0.394 in) |
| Class or Grade | ISO 898-1 Class 12.9 |
| Thread Size (Diameter × Pitch) | M4x0.7 mm |
| Coating | Zinc Flake |
| Thread Size | M4 mm (0 in) |
Compatible Equipment
- Track Loaders: 953D, 953, 963, 953K, 963K, 972, 982, 995, 992
- Cold Planers: PL83, PM620, PM622
- Compactors: CB16, CS56B, CS74B, CS68B, CS78B, CS12, CS-583D, CP56B, CB-14B, CB13, CB15
- Engines: C13, C175-16
- Excavators: 307.5, 330, 303.5E2 CR, 3126, 305, 320D, 313, 313 GC, 316 GC, 305E2 CR, 374, 349F L, 432, 312 GC, 336, 352, 301.8, 323 GX, 320 GX, 326, 323, 320 GC, 336 GC, 325, 340, 315, 320, 305 CR, 326 GC, 333 GC, 333, 355, 323 GC, 320D L, 315 GC, 350, 637K, 301.6, 330GC, 330 GC, 320D3 GC, 345 GC, 335, 349, 395, 350MHPU, 621K, 320B, 349E L VG, 349E L, 6020B, 352F, 6040, 325B L, 323GC, 349E, 621H, 302.7CR, 320D3, 326GC, 6030, 303.5CR, 303CR, 3101
- Asphalt Pavers: AP355F, AP300F, AD30
- Skid Steer Loaders: 232D3, 226D3, 236D3, 246D3, 232D, 262D, 259D3, 249D3, 262D3, 236D, 289D3, 242D3, 246D, 216B3, 24, 239D3, 299D3 XE, 272D3 XE, 279C, 246C, 262C, 272D3, 226B3
- Motor Graders: 120, 18, 16M3, 14, 14M, 16, 16M, 349 GC, 120H
- Wheel Excavators: IT14G, M320, M315, M315GC
- Dozers: D7, D11, D6K2, D8T, D6T, D3K2 LGP, D5K2 XL, D7R II, D6T LGP, D6N, D4, D9, D9T, D1, D8, D10T2, D11T, D10, D5M, D6M
- Compact Track Loaders: 299D3, 279D3
- Mini Excavators: 302CR, 301.7CR, 301.5, 310, 306, 305E2, 308, 308.5, 305.5E2, 306.5
- Wheel Loaders: R2900 XE, 950L, 950, 962L, 980, R1700K, M314, 938K, 938M, 910, 924K, 926M, 962G, R1700 XE, 950G, 966, 928G, 966H, 906K, 950H, 836
- Off-Highway Trucks: 777, 794 AC, 789D, 797F, 798 AC, 785, 796 AC, 793F, 793, 773, 789, 793D, 775G
