Description
Metric
Cat bolts form a matched system with mating hardened washers and nuts to produce consistent, high clamping force.
Features
- Thread Size: M10
- Material: Steel
- Galvanized
Specifications
| Thread Size | M10 mm (0 in) |
|---|---|
| Hex Size | 13 mm (0.51 in) |
| Material | Carbon Steel |
| Locking Feature | None |
| Thread Direction | RH |
| Class or Grade | ISO 898-1 Class 8.8 |
| Thread Size (Diameter × Pitch) | M10x1.5 mm |
| Bolt Length | 85 mm (3.346 in) |
| Bolt Type | Hex Flange Head Bolt |
| Coating | Zinc |
| Handle Length | 59 mm (2.323 in) |
Compatible Equipment
- Generator Sets: 3512B, C4.4, C7.1
- Compactors: CB1.7, CB1.8, CW-34, CW-16, CB-66B, CS-56, CP54B, CS79B, CS74B, CB16, CC-34B, CS56B, CS-54, CS54B, CS68B, CP56B, CS78B, CB-14, CB-64B, CB-44B, CS11, CS12, CS7, CB10, CB15, CB13, CS-54B, CS64B
- Engines: C6.6
- Excavators: 320D2, 329D2, 326D2 L, 329D2 L, 326D2, 330, 320D, 316 GC, 330 GC, 320 GX, 320D L, 120 GC, 320 GC, 320D2 GC, 318D2, 323, 313D2, 326GC, 330D2, 323D2 L, 312D2, 326, 312D2 L, 318D2 L, 313D2 GC, 312D2 GC, 330D2 L, 320, 323D2, 336 GC, 323GC, 313D2-GC, 323D L, 320D GC, 326 GC, 333 GC, 333
- Asphalt Pavers: AP655F, AP655F L, AP-600D
- Skid Steer Loaders: 226B, 313D2 LGP, 226B3, 216B3, 236
- Wheel Excavators: M320D2, M322D, M315D, M313D, M317D2, M315D2, M320, M315GC, M315
- Mini Excavators: 301.5, 301.7CR, 302CR
- Wheel Loaders: 928HZ, 924HZ, R1300G
- Off-Highway Trucks: 745, 730, 735, 725
Additional information
| Machine Model | 120 GC, 216B3, 226B, 226B3, 236, 301.5, 301.7CR, 302CR, 312D2, 312D2 GC, 312D2 L, 313D2, 313D2 GC, 313D2 LGP, 313D2-GC, 316 GC, 318D2, 318D2 L, 320, 320 GC, 320 GX, 320D, 320D GC, 320D L, 320D2, 320D2 GC, 323, 323D L, 323D2, 323D2 L, 323GC, 326, 326 GC, 326D2, 326D2 L, 326GC, 329D2, 329D2 L, 330, 330 GC, 330D2, 330D2 L, 333, 333 GC, 336 GC, 3512B, 725, 730, 735, 745, 924HZ, 928HZ, AP-600D, AP655F, AP655F L, C4.4, C6.6, C7.1, CB-14, CB-44B, CB-64B, CB-66B, CB1.7, CB1.8, CB10, CB13, CB15, CB16, CC-34B, CP54B, CP56B, CS-54, CS-54B, CS-56, CS11, CS12, CS54B, CS56B, CS64B, CS68B, CS7, CS74B, CS78B, CS79B, CW-16, CW-34, M313D, M315, M315D, M315D2, M315GC, M317D2, M320, M320D2, M322D, R1300G |
|---|---|
| Equipment Type | Excavators, Mini Excavators, Wheel Excavators, Wheel Loaders, Skid Steer Loaders, Off-Highway Trucks, Compactors, Asphalt Pavers, Engines, Generator Sets |
| Part Source | Genuine OEM |
