Description
The bolt material hardness and thread design provide high strength and resistance to bolt thread stripping.
Specifications
| Class or Grade | ISO 898-1 Class 10.9 |
|---|---|
| Thread Direction | RH |
| Locking Feature | None |
| Thread Size | M8 mm (0 in) |
| Thread Size (Diameter × Pitch) | M8X1.25 mm |
| Bolt Length | 40 mm (1.575 in) |
| Bolt Type | Hex Head Bolt |
| Coating | Zinc Flake |
| Handle Length | 4 mm (0.148 in) |
| Material | Low Alloy Steel |
Compatible Equipment
- Generator Sets: 3516C, 3512B, C9, C4.4, G3516C, 3512E, C7.1, G3516
- Track Loaders: 824G, 816F, 826G, 973K, 963K, 834H, 826H, 953K, 994K, 963, 992, 982, 972, 826K, 990K, 993, 995
- Cold Planers: PM620, PL83, PL61, PM622, SE60 VT XW, TH360B, PL72, PL87, SE50 VT
- Compactors: CB1.7, CB1.8, CB-44B, CS-56, 815, 814, CS7, 825K, 824K, CS-563E, CP54B, CW-16, CB-24B, CS74B, CP56B, CS68B, CS-583D, CB-34B, CB-66B, CB-64B, CS12, CC-34B, CS-533C, CS-54, CS11, CB-36B, CS78B, CS56B, CB16, CP11 GC, CS54B, 834K, CB2.5, CB2.7, CP12 GC, CS12 GC, C9.3B, CB2.5 GC, CB2.9, CS79B, CC2.7 GC, CB2.7 GC, 816, CB10, CB15, CB13, CS-54B, CS-533E, CS64B
- Engines: C15, C13, C32, C7, C27, C11, C18, C175-16, C12
- Excavators: 320D, 303.5E2 CR, 308D, 320D2, 336D2, 329D, 326D2, 3126, 329D2 L, 306E2, 329D2, 326D2 L, 307.5, 336D, 330, 330D L, 305E2 CR, 325C, 323D L, 330C, 312C, 320C, 314D LCR, 329D L, 340D L, 3512C, 416E, 428F, 416F2, 3516B, M325D L MH, 330C L, 120 GC, 637K, 657G, SE60 V XW, 305 CR, 318D2, 6060, 320D3 GC, 336F L XE, 315D L, 336D L, 328D LCR, 325D L, 324D L, 336F LN, 320D2 L, 432, 330D, 320D FM, 312C L, 320D L, 311C, 325D, 320B, 323D2 L, 324D, 330D2, 336F, 621H, 336F L, 313D, 320D3, 352F, 345D L, 3516E, 345B, 336E L, 6015, 6040, 336D2 L, 326D L, 314C, 315F LCR, 329E L, 336E LN, 314D CR, 320D2 GC, 320D RR, 318D2 L, 330 L, 325C L, 325B, 312D, 325B L, 313F LGC, 320D GC, 621K, 336E LH, 320C L, 323D, 330D2 L, 302.7CR, 336D2 GC, 318D L, 434F2, 6015B, 336E, 326, 6020B, 340D2 L, 303CR, 6030, 329E, 323D2
- Asphalt Pavers: AP355F, AD45, AP655F, AP300F, AP-600D, AP655F L
- Skid Steer Loaders: 272D3 XE, 299D3 XE, 289D3, 242D3, 259D3, 3126B, 236D3, 262D3, 279C, 236B3, 236, 246D3, 262C, 239D3, 246C, 246D, 249D3, 236D, 272D3
- Motor Graders: 14M, 140 GC, 14, 160K, 16M, 120, 140K, 140H, 18, 16, 12K, 12H, 16H, 140G, 120H
- Wheel Excavators: M315, M315D, M322D, M320D2, MD6200, M317D2, M313D, M315D2, IT14G, M320
- Dozers: D11T, D6N, D6K2, D6T, D7E, D1, D3K2 LGP, D6T LGP, D5K2 XL, D8T, D5N, D6R III, D7R, D7, D10T2, D6R, D7R II, D9T, D6R II, D6R XL, D9, D8, D4, D10R, D10T, D10
- Compact Track Loaders: 299D3, 279D3
- Mini Excavators: 305.5E, 306, 306.5, 305.5E2, 303.5E, 307C, 305E2
- Wheel Loaders: 966K, 938K, 980H, 980G, 962G, 950G, 950H, 972H, 972G, 962L, 966H, 924K, 928G, 972L, 986H, 988G, 988H, RM500B, RM400, 928HZ, 834, M314, R2900G, 950, 910, 966, R1600H, 924HZ, 966F, 938M, 988K, 966L, 906K, 980L, 924GZ, 950 GC, 980, 950L, 926M, R1700 XE, R1700K, R2900 XE, R3000H, R1700G
- Off-Highway Trucks: 797F, 730, 770G, 798 AC, 773F, 772G, 740 GC, 725, 793F, 735, 745C, 796 AC, 773, 785, 740, 725C2, 775G, 793, 789, 794 AC, 777, 745, 789D, 793D, 740B, 777E
