Description
The bolt material hardness and thread design provide high strength and resistance to bolt thread stripping.
Specifications
| Class or Grade | ISO 898-1 Class 10.9 |
|---|---|
| Thread Direction | RH |
| Locking Feature | None |
| Thread Size | M16 mm (0 in) |
| Thread Size (Diameter × Pitch) | M16X2 mm |
| Bolt Length | 55 mm (2.165 in) |
| Bolt Type | Hex Head Bolt |
| Coating | Zinc Flake |
| Handle Length | 6 mm (0.236 in) |
| Material | Steel |
Compatible Equipment
- Generator Sets: G3516C
- Track Loaders: 972, 982, 990K, 973K, 993, 992, 963D, 995, 994K
- Cold Planers: PM622, PM620, TH417D
- Engines: C7, C175-16
- Excavators: 374D L, 390D L, 307.5, 313, 313 GC, 349F L, 6015B, 365C L, 365C, 385C, 365B, 385B, 365B L, 320D3 GC, 315 GC, 320D3, 6030, 6060, 6015, 6020B, 312C, 312D, 320C, 325B L, 315, 323D L, 324D L, 325D, 324D, 325, 312E L, 336F L XE, 315D L, 320, 320B, 312D L, 312E, 325C, 315C, 320 GC, 311B, M325D L MH, 385C L, 390D, 385C FS, 352F, 374F L
- Asphalt Pavers: AP-600D
- Skid Steer Loaders: 226D3, 236D3, 232D3
- Motor Graders: 14, 120
- Wheel Excavators: M315, M320, MD6310, M315GC, M315D, M313D, M322D, MD6200, M315D2, M320D2
- Compactors: CB10
- Dozers: D11T, D10T2, D11, D10, D8, D3K2 LGP, D4G, D5K LGP, D5K2 XL, D3G, D5G, D5K XL, D1
- Mini Excavators: 306, 308, 306.5, 308.5, 310, 303.5D
- Wheel Loaders: 950, 980, 950 GC, 966, R2900 XE, 950L, 988K, 926M, 924K, M314, 938K, 962L, 938M, R1700 XE, R1700K, RM400
- Off-Highway Trucks: 745, 797F, 796 AC, 740, 793F, 798 AC, 740 GC, 794 AC, 7495, 745C, 793, 735, 725, 730, 789, 777
