Description
Machine screws are available in a variety of head styles, drive types, sizes, and materials.
Cat® fastener parts are designed for specific applications based on size, strength, clamp load and past performance, information other manufacturers do not have. They are carefully selected to last until machine rebuild or end of life. Non-Cat hardware and fasteners may appear to fit your machine, but no one else knows your equipment the way we do.
Features
- Cat fasteners are manufactured to precise specifications for durability, reliability and high efficiency
- Strength and Quality – Fasteners meet or exceed ISO, ASTM, ASME and SAE requirements.
- Cat bolts, nuts and washers are specifically designed to work together as a system to maximize clamping force.
- Coating meets the special requirements of different applications (RoHS compliant).
Applications
Cat bolts form a high-performance system with mating hardened washers and nuts to produce consistent, high clamping force. You can trust Cat fasteners to help you build, maintain or rebuild in most machine and shop applications worldwide.
Specifications
| Thread Size | M5 mm (0 in) |
|---|---|
| Bolt Type | Rounded Head (Pan) |
| Class or Grade | ISO 898-1 Class 4.8 |
| Bolt Length | 8 mm (0.315 in) |
| Thread Direction | RH |
| Thread Size (Diameter × Pitch) | M5X0.8 mm |
| Screw Type | Machine Screw |
| Material | Steel |
| Locking Feature | Not Specified |
| Length | 8 mm |
| Head Type | Oil Pan |
| Head Height | 3.7 mm |
| Head Diameter | 9.5 mm |
| Handle Length | 1.6 mm (0.063 in) |
| Groove Type | Phillips + Slotted |
| Drive Chain | #2 in |
| Coating | Zinc Electroplated |
Compatible Equipment
- Generator Sets: 3512B
- Motor Graders: 316F
- Wheel Excavators: M313D, M315, M315D, M322D
- Engines: C32
- Compactors: CB10
- Mini Excavators: 306, 307, 307B, 307D, 308, 305.5, 308.5, 310, 307C, 307E2, 302CR, 305.5E2, 305.5E, 308E2
- Excavators: 313, 374, 349F L, 313 GC, 330D L, 352, 340, 374F L, 345C L, 345C, 349D L, 349E L, 349, 352F, 6015B, 345B, 390D, 365B L, 385B, 390F, 385C, M325D L MH, 328D LCR, 320D L, 315 GC, 395, 336D L, 302.7CR, 303CR, 303.5CR, 313D2, 320 GC, 320, 320D3, 326, 336 GC, 336, 345 GC, 6015, 305 CR, 320 GX, 323 GC, 325, 324D, 313D2 GC, 311D LRR, 318D2 L, 323GC, 312C, 314D LCR, 320D2 L, 320C, 336F LN, 312D2 L, 323, 325D L, 329E L, 325D, 320C L, 313D, 323D L, 330C L, 315D L, 330C, 345D L, 365B, 385C L, 385C FS, 365C L, 345D, 340D L, 365C, 349E, 340D2 L, 349E L VG, 301.8, 324D L, 312D L, 325B, 330D2 L, 336F L XE, 336D2 L, 320D RR, 312D, 311B, 330GC, 329D L, 315C, 323D2 L, 320B, 336D2 XE, 312D2, 320D GC, 313F L, 320D FM, 325C L, 314C, 336F, 336F L, 335F LCR, 336E L, 325C, 330 L, 312F, 320E, 336E LH, 320D2 GC, 315, 330D2, 320D3 GC, 335, 350, 323D, 325B L, 330 GC, 301.6, 336E, 329E, 315F LCR, 326D L, 314D CR, 311C, 326GC, 336D2 GC, 312E L, 323D2, 330D, 313D2-GC, 3101, 318D L, 336E LN, 312E, 312D2 GC, 336E H, 312C L, 350 L, 330B, 313F LGC, 320D, 330, 320D2, 349D2 L, 349D, 390F L, 305, 307.5, 336D, 336D2, 349D2, 374D L, 374F, 390D L, 303, 329D2, 326D2 L, 329D, 307E, 326D2, 329D2 L, 306E, 308D, 308E, 306E2
- Wheel Loaders: 980H
- Skid Steer Loaders: 313D2 LGP
