094-0611 1 mm Thick Washer
Cat® washers in planetary gear systems act as spacers, keeping the planetary gears properly aligned and distributing force between the planetary gears.
Description
Retains the roller bearings in the final drive assembly and swing drive assembly.
Features
- Material: Steel
- Hardened
- Outside Diameter: 76 mm (2.99 in)
- Inside Diameter: 47.3 mm (1.86 in)
- Thickness: 1 mm (0.04 in)
Specifications
| Gasket Type | Flat |
|---|---|
| Outside Diameter | 76 mm (2.992 in) |
| Inside Diameter | 47.3 mm (1.862 in) |
| Thickness | 1 mm (0.039 in) |
| Coating | None |
Compatible Equipment
- Generator Sets: 3512B, C7.1
- Dozers: D1, D3K2 LGP, D5K2 XL, D5K LGP, D5K XL
- Excavators: 349F L, 323D2 L, 352, 320, 320D FM, 320D2 L, 325B L, 315D L, 325C, 320D L, 323D L, 320C, 325D L, 323, 330 GC, 320D2 GC, 320 GC, 328D LCR, 329E, 311C, 315C, 320D GC, 330D2 L, 324D, 329D L, 320D RR, 320B, 325D, 324D L, 330D2, 329E L, 318D2 L, 320E, 323 GX, 320 GX, 318D L, M325D L MH, 365B L, 349, 320D3, 325B, 325C L, 326D L, 323D, 335F LCR, 318D2, 323D2, 320C L, 313D2, 352F, 365C, 349E, 365B, 374F L, 349D L, 365C L, 349E L, 349E L VG, 320D, 320D2, 330, 329D, 326D2, 329D2, 329D2 L, 326D2 L, 374D L, 374F, 349D2 L, 349D2
- Skid Steer Loaders: 313D2 LGP
Additional information
| Machine Model | 311C, 313D2, 313D2 LGP, 315C, 315D L, 318D L, 318D2, 318D2 L, 320, 320 GC, 320 GX, 320B, 320C, 320C L, 320D, 320D FM, 320D GC, 320D L, 320D RR, 320D2, 320D2 GC, 320D2 L, 320D3, 320E, 323, 323 GX, 323D, 323D L, 323D2, 323D2 L, 324D, 324D L, 325B, 325B L, 325C, 325C L, 325D, 325D L, 326D L, 326D2, 326D2 L, 328D LCR, 329D, 329D L, 329D2, 329D2 L, 329E, 329E L, 330, 330 GC, 330D2, 330D2 L, 335F LCR, 349, 349D L, 349D2, 349D2 L, 349E, 349E L, 349E L VG, 349F L, 3512B, 352, 352F, 365B, 365B L, 365C, 365C L, 374D L, 374F, 374F L, C7.1, D1, D3K2 LGP, D5K LGP, D5K XL, D5K2 XL, M325D L MH |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
