Description
The window latch is integrated into the door assembly and works in conjunction with the window mechanism. The latch consists of several components, including a locking mechanism, a latch bolt and related fasteners. In a manual lock, a mechanical mechanism (such as a lever or rotary cylinder) is used to engage or disengage the lock. The latch bolt is responsible for holding the window in the closed position and engages the corresponding strike plate on the window frame, ensuring a tight and secure fit.
Features
- Attractive design blends seamlessly with the vehicle interior.
- Designed to fit snugly in a specific slot.
Applications
The window latch ensures that the window remains securely closed and prevents unauthorized entry into the vehicle interior.
Specifications
| Height | 38 mm (1.496 in) |
|---|---|
| Overall Height | 38 mm (1.5 in) |
| Length | 81 mm (3.188 in) |
| Overall Length | 81 mm (3.19 in) |
| Material Description | Polyoxymethylene Plastic |
| Overall Width | 24 mm (0.95 in) |
| Width | 24 mm (0.94 in) |
| Weight | 0.02 kg (0.04 lb) |
Compatible Equipment
- Motor Graders: 349 GC, 316F
- Generator Sets: 3512B, C7.1
- Wheel Excavators: M320, M315, M315GC
- Mini Excavators: 307C, 305.5, 307B, 307D, 305.5E, 302CR, 306, 305.5E2
- Excavators: 313 GC, 330D L, 313, 374, 316 GC, 349F L, 340, 352, 350, 355, 336D2 L, 325, 365C, 323D2 L, 330C L, 320D L, 385C FS, 385C, 320C, 385C L, 323D L, 325C, 330C, 320D FM, 320D2 L, 324D, 318D2 L, 325D L, 318D2, 312C L, 315C, 312C, 312D2 L, 336D L, 302.7CR, 303CR, 303.5CR, 313D2, 315 GC, 320 GC, 320, 326, 336 GC, 336, 345 GC, 349, 395, 6015, 345C L, 325D, 324D L, 326 GC, 333 GC, 333, 323 GX, 320 GX, 313 GX, 323 GC, 330 GC, 316 GX, 312 GX, 3101, 313D, 330D2, 336D2 GC, 329D L, 301.8, 313F L, 326GC, 312D2 GC, 336F L XE, 330GC, 329E L, 336F, 336F L, 312D L, 325B, 315D L, 329E, 320D GC, 336E, 314D LCR, 336E L, 330B, 320E, 325B L, 323, 336D2 XE, 312D, 312D2, 325C L, 336E LH, 320B, 330D, 311D LRR, 328D LCR, 330D2 L, 312E, 349E L, 6015B, 345C, 349E, 352F, 345D L, 390F, 350 L, 349D L, 345D, 340D2 L, 345B, 374F L, 349E L VG, 340D L, 320D RR, 336F LN, 323GC, 330 L, 312E L, 314C, 312F, 311B, 311C, 323D2, 313F LGC, 320D2 GC, 320C L, 314D CR, 301.6, 336E H, 313D2-GC, 315F LCR, 323D, 318D L, 335F LCR, 315, 336E LN, 326D L, 312 GC, 350MHPU, 335, 313D2 GC, 365C L, 320D, 320D2, 330, 336D2, 326D2 L, 326D2, 306E2, 306E, 329D2 L, 349D2 L, 349D2, 390F L, 374F, 349D, 308D, 329D, 329D2, 336D
- Wheel Loaders: M314
- Skid Steer Loaders: 313D2 LGP
