9W-4195 Bearing
Track Roller and Idler Bushing (Bronze Support)
Wholesale only · Full payment before shipment · Send your machine nameplate to confirm fitment
Description
Bronze-supported track roller and idler bushings provide a large surface area to better distribute the load within the carrier roller. The inside diameter surface is smoothly polished, and the soft bronze coating inside the bearing can absorb any small foreign particles, preventing them from damaging the shaft and seals.
Specifications
| Chassis Width | 120 mm |
|---|---|
| Track Shoe Type | Moderate Duty, Single Grouser |
| Bolt Size | 5/8 mm (5/8 in) |
| Diameter | 169.02 mm |
| Track Pitch | 190.5 mm (7.5 in) |
| Track Shoe Width | 610 mm (24 in) |
| Material | Steel Backed Bronze Bearing |
| Cross Hole | No |
| Ferrule Inside Diameter | 162.84 mm (6.411 in) |
| Unique Features | No |
| Overall Length | 120 mm (4.724 in) |
| Ferrule Outside Diameter | 169.02 mm (6.654 in) |
Compatible Equipment
- Dozers: D11R, D11N
