159-8127 Blade Tilt Cylinder Bracket
Cat® Blade Tilt Cylinder Bracket, Bracket Bore Diameter: 77.45 mm
Description
Part 159-8127 is a cast iron blade tilt cylinder bracket on certain motor grader models, including the bracket, cover, and mounting fasteners.
Features
- Cast iron bracket with fasteners and cover
- Bracket Bore Diameter: 77.45 mm (3.05 in)
- Height: 310 mm (12.2 in)
- Hole Size: 32 mm (1.3 in) (2X); 40 mm (1.6 in) (2X)
- Thread Sizes: 3/8-16 (2X); 1/2-13 (6X)
Applications
Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Length | Not Specified mm (Not Specified in) |
|---|---|
| Width | Not Specified mm (Not Specified in) |
| Height | 310 mm (12.2 in) |
| Hole Size | 32 (2X); 40 (2X) mm (1.3 (2X); 1.6 (2X) in) |
| Thread Size | 3/8-16 (2X); 1/2-13 (6X) in |
Compatible Equipment
- Motor Graders: 140H, 12H, 120H, 160K, 140K
