Description
Tapered roller bearings reduce friction between mating parts and provide protection. They are specifically designed to handle large radial and thrust loads.
Features
- Inside Diameter: 76.2 mm (3.000 in)
- Outside Diameter: 139.992 mm (5.511 in)
- Width: 73.431 mm (2.8909 in)
- To ensure that every Cat bearing meets specific design and application requirements, Caterpillar has invested significant time and money in research and development. Many of these products incorporate one or more special features not previously seen in industry-standard bearings. The result is fewer repairs needed, along with reduced downtime and operating costs.
Applications
Cat bearings are built for specific applications to ensure that all power train components operate as a whole and withstand wear. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Material | Alloy Steel |
|---|---|
| Inside Diameter | 76.2 mm (3 in) |
| Outside Diameter | 139.992 mm (5.511 in) |
| Width | 73.431 mm (2.8909 in) |
Compatible Equipment
- Motor Graders: 14, 160K, 140K, 12K
- Compactors: CS-563E, CS56B, CS74B, CS79B, CP56B, CS68B, CS-56, CS-583D, CS78B, CS12, CS-54, CS-533E
