7N-9738 Receptacle Housing

Description

Cat connectors use a pin-and-socket connection system to provide reliable electrical connections across a range of electrical applications on Cat heavy-duty equipment. Quality that suits your equipment requirements and meets your expectations.

Features

Wire Size: 14-18 AWG
Number of Contacts: 3
Connector accepts 2 pins and 1 sockets
Waterproof
Easy to connect and disconnect

Applications

Cat connector plug groups provide a reliable mating connection between wires or between a wire and equipment.

Specifications

Length	39.37 mm (1.55 in)
Outside Diameter	18.03 mm (-0.71 in)

Compatible Equipment

Generator Sets: G3516, 3406C, 3406B, 3512B, 3516C, C9
Track Loaders: 824C, 953, 816F, 963
Engines: C32, C7, C27, C15, C13, C11, C12, C18
Excavators: 3126, 3456, 3516B, 330 L, 637E, 3512C, 3508B, 416E, 350 L, 621G, 330C, 320C, 3516E, 637G
Asphalt Pavers: AD45
Skid Steer Loaders: 3126B
Motor Graders: 140G, 120H, 3606, 12H, 140H
Compactors: C-15
Dozers: D9R, D7H, D6R, D8L, D9N, D9L, D5H, D8N, D5M, D8R, D7R, D7G, D11N, D10, D10N, D6M, D7G2, D11R, D6G
Mini Excavators: 307
Wheel Loaders: 928G, 966F, 962G, 972G, 992C, RM500B, R1700 II, 980G, R1700G, 924GZ, 836
Off-Highway Trucks: 793D, 785D, 740, 777, 735, 771D, 777D, 789D, 773E, 773D, 785, 789, 793, 773

Machine Model	120H, 12H, 140G, 140H, 307, 3126, 3126B, 320C, 330 L, 330C, 3406B, 3406C, 3456, 350 L, 3508B, 3512B, 3512C, 3516B, 3516C, 3516E, 3606, 416E, 621G, 637E, 637G, 735, 740, 771D, 773, 773D, 773E, 777, 777D, 785, 785D, 789, 789D, 793, 793D, 816F, 824C, 836, 924GZ, 928G, 953, 962G, 963, 966F, 972G, 980G, 992C, AD45, C-15, C11, C12, C13, C15, C18, C27, C32, C7, C9, D10, D10N, D11N, D11R, D5H, D5M, D6G, D6M, D6R, D7G, D7G2, D7H, D7R, D8L, D8N, D8R, D9L, D9N, D9R, G3516, R1700 II, R1700G, RM500B
Equipment Type	Excavators, Mini Excavators, Wheel Loaders, Track Loaders, Skid Steer Loaders, Dozers, Motor Graders, Off-Highway Trucks, Compactors, Asphalt Pavers, Engines, Generator Sets
Part Source	Genuine OEM

Machine Model

120H, 12H, 140G, 140H, 307, 3126, 3126B, 320C, 330 L, 330C, 3406B, 3406C, 3456, 350 L, 3508B, 3512B, 3512C, 3516B, 3516C, 3516E, 3606, 416E, 621G, 637E, 637G, 735, 740, 771D, 773, 773D, 773E, 777, 777D, 785, 785D, 789, 789D, 793, 793D, 816F, 824C, 836, 924GZ, 928G, 953, 962G, 963, 966F, 972G, 980G, 992C, AD45, C-15, C11, C12, C13, C15, C18, C27, C32, C7, C9, D10, D10N, D11N, D11R, D5H, D5M, D6G, D6M, D6R, D7G, D7G2, D7H, D7R, D8L, D8N, D8R, D9L, D9N, D9R, G3516, R1700 II, R1700G, RM500B

Equipment Type

Excavators, Mini Excavators, Wheel Loaders, Track Loaders, Skid Steer Loaders, Dozers, Motor Graders, Off-Highway Trucks, Compactors, Asphalt Pavers, Engines, Generator Sets

Part Source

Genuine OEM
